【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
Comes with Japanese customer technical support and a Japanese instruction manual for safe operation.
[Function] Three-phase phase order detection (positive phase, negative phase, open phase), live line inspection, simple voltage detection, caustic wire identification, open phase determination, disconnection position search, DC line disconnection detection, line inspection, etc.
[Safety] Adopts a clamp-type non-contact induction measurement, there is no need to peel off the outer sheath of the electric cable, and the phase order can be inspected by directly sandwiching the three super-inductive high-insulation clamps between the insulating outer sheath of the three-phase flame wire, without touching the high-voltage open flame wire.
[Easy to use] A magnet is attached to the bottom plate of the phase detector meter, and the meter can be attracted to the metal case of the equipment during testing, making it convenient to operate. Data can be seen at a glance with real-time audio and LCD display.
[Specifications] Non-contact phase detector measurement voltage: AC 70V-1000 V. Safety regulations: EN 61010-1:2001, EN 61010-031:2002, pollution level 2, CAT 3 (600 V), transient overvoltage 6000 V.
specification:
Model: ETCR1000D Non-contact phase detector
Functions: phase detection (positive phase, negative phase, and phase loss), live line inspection, simple power detection, breakpoint location and line maintenance.
Power supply: DC 3V2 * AA alkaline battery, 70 hours continuous operation
Clamp wire size: outer diameter 10-40mm
The four phase sequence lamps will light up in sequence (clockwise).
(Reverse phase sequence)
The four phase sequence lamps will light up in sequence (counterclockwise).
(Live Power) L1, L2, and L3 lamps light up within the voltage setting range.
(Phase loss) L1 or L2 or L3 will not light up.
(Short circuit) L1 or L2 or L3 does not light up.
buzzer:
(positive phase) The device emits short beeps intermittently;
(Reverse Phase) The device emits a continuous long beep.
After 5 minutes, the meter will automatically cut off the power.
meter dimensions
Width, height, thickness 70mm*75mm*30mm
Clamp lead length: 0.6m
Weight: 317g
Working temperature and humidity: -10℃-55℃. Less than 80% rh
Storage temperature and humidity: -20℃-60℃. Less than 90% rh
Maximum measurement voltage: AC 1000V
Safety regulations: EN61010-1:2001, EN61010-031:2002, pollution level 2, CAT 3 (600V), transient overvoltage 6000V
accessories:
Non-contact phase detector x1
Japanese instruction manual x1
Storage pouch x1
*Due to import regulations and customs reasons, this product does not include batteries, so please prepare them in advance
Note: The color of the actual product may differ from the photo due to light.
There may be slight deviations in product measurements.
